EKL6-100B Type B RCCB Comprehensive AC/DC Leakage Protection for Modern Electrical Systems (16A-100A)
Why Quality Matters?
Grouped by product family for cleaner RFQ selection: one page shows the available variant SKUs and key specification choices without creating duplicate product pages.
Variant SKU:
RFQ inputs
Quantity, destination, certificate needs.
QC proof
Inspection and document review before shipping.
Export ready
Packaging and mixed-container planning.
Procurement Snapshot
Commercial details are confirmed by SKU, quantity and destination at RFQ stage.
RFQ checklist
Send these points with your inquiry for faster pricing.
Documents to confirm
Often sourced together
Technical Data
Specification values for buyer review and RFQ matching
| Product Family ID | OS-ETK-EKL6-100B |
|---|---|
| Variant SKU Count | 1 |
| Supplier | ETK |
| Supplier Model | EKL6-100B |
| Product Type | RCCB |
| Available Voltage Ratings | 1P+N: 230/240V~, 3P+N: 400/415V~ |
| Rated Voltage | 1P+N: 230/240V~, 3P+N: 400/415V~ |
| Rated Current | 2P: 16,25,32,40,63A, (80,100A(3 modules)) |
| Protection Degree | IP20 |
| Operating Temperature | -25°C to +40°C, Max.95% humidity |
| Poles | 2P(1P+N): 110/230/240V, 4P(3P+N): 240/400/415V |
| Protection Degree | IP20 |
| Rated Current | 2P: 16,25,32,40,63A, (80,100A(3 modules)) |
| Rated Voltage | 1P+N: 230/240V~, 3P+N: 400/415V~ |
| System Voltage | 1P+N: 230/240V~, 3P+N: 400/415V~ |
Product Overview
Type B RCCB in the 16A to 100A range for detecting AC, pulsating DC, and smooth DC leakage in main distribution board positions where overcurrent protection is handled separately by downstream MCBs or MCCBs. The higher current range suits commercial and industrial distribution boards where a single Type B main RCCB protects multiple downstream circuits.
Specifying Type B at the main RCCB position covers the entire downstream circuit for all leakage types, regardless of the mix of load types on the board — simpler than specifying Type B on individual circuit breakers.
100A Type B RCBO covers large single-phase inverter outputs or grouped small-inverter circuits where aggregate current approaches 100A. The B-type detection characteristic adds protection against smooth DC residual currents — verify whether your inverter specifies Type B RCD in its installation manual before substituting a standard Type AC device.
Applications
Inverter output protection
AC distribution boards
EV and PV support circuits
Residential and commercial electrical BOS
Frequently Asked Questions
Why choose a Type B RCCB without overcurrent protection?
Separating residual current and overcurrent functions is standard practice in industrial distribution where different engineers govern each protection function. The RCCB is sized for the board incoming current; downstream MCCBs or MCBs handle individual circuit overcurrent protection.
What is the residual current sensitivity?
Available sensitivity ratings for high-current RCCBs include 30mA, 100mA, and 300mA. Specify the required sensitivity at RFQ — 300mA is common for fire protection in main distribution, 30mA for personal protection circuits.
Technical Guides
Products & Systems
Markets & Services
Need project-specific engineering support?
Free CAD layout, wind/snow load calculations, and BOM review included with project orders.
Related Products
More components from the same application category.
EKL6-100 RCCB: Magnetic Residual Current Circuit Breaker for Industrial and Commercial Applications
