EKF1-10PV 1000VDC 32A 10x38mm gPV Fuse Switch Disconnector for Photovoltaic Systems
Why Quality Matters?
Grouped by product family for cleaner RFQ selection: one page shows the available variant SKUs and key specification choices without creating duplicate product pages.
Variant SKU:
RFQ inputs
Quantity, destination, certificate needs.
QC proof
Inspection and document review before shipping.
Export ready
Packaging and mixed-container planning.
Procurement Snapshot
Commercial details are confirmed by SKU, quantity and destination at RFQ stage.
RFQ checklist
Send these points with your inquiry for faster pricing.
Documents to confirm
Often sourced together
Technical Data
Specification values for buyer review and RFQ matching
| Product Family ID | OS-ETK-EKF1-10PV |
|---|---|
| Variant SKU Count | 1 |
| Supplier | ETK |
| Supplier Model | EKF1-10PV |
| Product Type | PV Fuse / Fuse Holder |
| Available Voltage Ratings | 1000 VDC |
| Rated Voltage | 1000 VDC |
| Protection Degree | IP20,after installation |
| Operating Temperature | -5°C ... +40°C |
| Poles | 1P |
| Protection Degree | IP20,after installation |
| Rated Voltage | 1000 VDC |
| System Voltage | 1000 VDC |
Product Overview
Combines a gPV fuse holder with an integrated isolating switch in one DIN rail device rated at 1000V DC, 32A, for 10×38mm fuse links. The switching function allows the fuse link to be replaced safely without de-energizing the full combiner bus — a requirement in many markets.
This device is directly compatible with EKFL10D10 cylindrical gPV fuse links. The 1000V DC rating covers standard PV string circuits; for 1500V systems use EKF1-15PV.
10A PV string fuses are standard protection for string Isc values up to 10A, typical of 72-cell standard modules in 1000V configurations. Verify that the fuse current rating is at least 1.25 times the string Isc and that the voltage rating covers the full open-circuit string Voc, including temperature correction for cold-climate sites.
Applications
PV string and array protection
Combiner box internal protection
Inverter DC input circuits
Utility and C&I solar BOS
Frequently Asked Questions
What is the advantage of a fuse switch disconnector over a basic fuse holder?
A fuse switch disconnector allows the operator to open the circuit before changing the fuse link, reducing the risk of working on a live conductor. Many electrical codes require switching capability at fuse positions to allow safe fuse replacement.
What fuse link current ratings are compatible?
10×38mm gPV fuse links from 8A to 32A are compatible with this holder. Select the fuse link at no more than 1.25× the string Isc. Compatible fuse links are EKFL10D10 — order fuse links alongside the holders for commissioning and maintenance stock.
Technical Guides
Products & Systems
Markets & Services
Need project-specific engineering support?
Free CAD layout, wind/snow load calculations, and BOM review included with project orders.
Related Products
More components from the same application category.
EKF1-10PVH Solar Photovoltaic Fuse Switch Disconnector - 1000VDC 32A with 10×38mm Fuse Link
EKF1-10PVH Solar Photovoltaic Fuse Switch Disconnector - 1000VDC 32A with 10×38mm Fuse Link is organ...
EKF1-15PV 1500VDC 35A Solar Photovoltaic Fuse Switch Disconnector with DIN Rail Mounting
EKF1-15PV 1500VDC 35A Solar Photovoltaic Fuse Switch Disconnector with DIN Rail Mounting is organize...
EKFL10D10 10x38mm 8A-32A 1000V Cylindrical Fuse Links for Solar Applications
