EKPC-D Solar PV String Monitoring Device
Why Quality Matters?
Grouped by product family for cleaner RFQ selection: one page shows the available variant SKUs and key specification choices without creating duplicate product pages.
Variant SKU:
RFQ inputs
Quantity, destination, certificate needs.
QC proof
Inspection and document review before shipping.
Export ready
Packaging and mixed-container planning.
Procurement Snapshot
Commercial details are confirmed by SKU, quantity and destination at RFQ stage.
RFQ checklist
Send these points with your inquiry for faster pricing.
Documents to confirm
Often sourced together
Technical Data
Specification values for buyer review and RFQ matching
| Product Family ID | OS-ETK-EKPC-D |
|---|---|
| Variant SKU Count | 1 |
| Supplier | ETK |
| Supplier Model | EKPC-D |
| Product Type | Solar PV String Monitoring Device |
| Available Voltage Ratings | DC50V~DC1500V |
| Rated Voltage | DC50V~DC1500V |
| Rated Current | 0~20A |
| Communication | RS485 / ModBus-RTU protocol |
| Input Channels | 8, 12, 16, 20, 24 |
| Operating Temperature | -30°C ~ +70°C |
| Rated Current | 0~20A |
| Rated Voltage | DC50V~DC1500V |
| System Voltage | DC50V~DC1500V |
Product Overview
PV string monitoring device measures current per string inside a combiner box, enabling per-string fault detection and performance monitoring without a full SCADA system. String-level current data identifies underperforming strings, open-circuit faults, and partial shading patterns that module-level or inverter-level monitoring cannot pinpoint.
Early detection of one failing string in a 12-string combiner can prevent months of reduced energy yield. EKPC-D installs inside the combiner box alongside existing fuse holders and reports string current data to a connected monitoring gateway.
The EKPC-D measures string current on individual PV string inputs in real time and transmits data via RS485 Modbus to a monitoring platform or logger. String-level current comparison allows fast identification of shading, soiling, or cell degradation on individual strings without a site visit — confirm monitoring platform Modbus address mapping before ordering.
Applications
PV string monitoring
Auxiliary power in solar BOS
Combiner and inverter support circuits
Project-specific electrical accessories
Frequently Asked Questions
How does string monitoring improve O&M efficiency?
Without string monitoring, a fault in one string of a combiner may reduce output by only a few percent — below the threshold detectable at the inverter. String current monitoring identifies the specific string and combiner, allowing technicians to go directly to the fault location instead of string-walking the entire array.
What communication protocol does EKPC-D use?
Confirm the communication protocol (RS485/Modbus, CAN, or proprietary) from the product datasheet. The monitoring device output must be compatible with the data logger or SCADA system collecting the data — share the SCADA system details at RFQ and we confirm compatibility.
